6351 T6 Aluminium Plate
Aluminum 6351 Plate is a grade of aluminum alloys. Their average alloy composition is basically identical. 64430 Aluminum Plate is a heat treatable alloy very similar to 6351 with similar characteristics including corrosion resistance and strength. Many European specifications now call up 6082 Aluminum Plate in lieu of Aluminum Plate 6351.
| Standard Dimensions of 6351 T6 Aluminium Plate: |
| Aluminium Alloy | ASTM B209 6351 T6 |
| Aluminium 6351 T6 Plate Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium 6351 T6 Plate Thickness | 0.5mm-150mm |
| Aluminium 6351 T6 Plate Width | 500-2000mm |
| Aluminium 6351 T6 Plate Length | to clients’ requirement |
| Aluminium 6351 T6 Plate Coating | Polyester, Fluorocarbon, polyurethane and epoxy coating |
| 6351 T6 Aluminium Plate Coating finish | PVDF, POLYESTER(PE) |
| Aluminium 6351 T6 Plate Surface | Polished, hair line, brush, sand blast, checkered, embossed, etching, etc. Mill finish, Bright finish, paper interleaved, one side film, both sides film. |
| Aluminium 6351 T6 Plate Gloss | Meet the customer requirement |
| Total coating thickness of Aluminium 6351 T6 Plate | PVDF coating: More than 25 micron; Polyester coating: More than 18 micron |
| Aluminium 6351 T6 Plate Coating hardness | (pencil hardness) more than 2H |
| Aluminium 6351 T6 Plate Coating adhesive | No lower than1st grade |
| Aluminium 6351 T6 Plate Impact resistance | No cracking or peeling (50kg/cm, ASTMD-2794: 1993) |
| Aluminium 6351 T6 Plate Flexibility (T-bend) | 2T |
| Aluminium 6351 T6 Plate MEK resistance | More than 10 |
| Available Aluminium 6351 T6 Plate Stock Sizes | 1ft x 1ft, 1ft x 2ft, 1ft x 4ft, 2ft x 2ft, 2ft x 4ft, 4ft x 4ft, 4ft x 8ft, 4ft x 10ft or Cut to Size or Custom Shape. |
| Aluminium 6351 T6 Plate Delivery Time | 30-60 days after receiving the prepayment |
| Aluminium 6351 T6 Plate Packaging Details | Standard export package. One pallet is about 2-3 ton.Two steel belts in width and three in width. One 20GP container can load about 18-20 tons Aluminium 6351 T6 Plate. One 40GP container can load about 24 tons Aluminium 6351 T6 Plate |
| ASTM B209 Alloy 6351 T6 Plate Outer packing | Export standard, wooden pallet |
| Bottom side Aluminium 6351 T6 Plate is coated with protective polyester material, thickness more than 6 micron | |
| We Export Aluminium 6351 T6 Plate to | Singapore, Indonesia, Ukraine, Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, USA, Egypt, Iran, China, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq, Russia, Malaysia, etc. |
| AUTHORIZED DISTRIBUTORS OF , NALCO, , THYSSENKRUPP, VIRGO, MANKASIA AND METENERE | |
| Types of 6351 T6 Aluminium Plate Manufacturer in China: |
| 6351 T6 Aluminium Plates Product Range | ||||
|---|---|---|---|---|
| Alloy No. | Thickness (mm) |
Width (mm) |
Length (mm) |
Temper |
| 6351 T6 Aluminium Plate | 0.2-5.0 | 20-2200 | 20-8000 | O, H12, H22, H14, H16, H18, H24, H26 |
| Standard Specification of 6351 T6 Aluminium Plate: |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-6351 | HE30 | 6351 | AlMgSi1 | AlSiMg0.5Mn | 64430 | B51S |
| EN AW-6082 | HE30 | 6351 | AlMgSi1 | AlSi1MgMn | 64430 | B51S |
| 6351 T6 Aluminium Plate Equivalent Grades: |
| China |
U.S.A. |
BRITAIN |
CANADA | GERMANY |
RUSSIA |
I.S.O. |
FRENCH | |
|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) |
(B.S.) |
(DIN) | – | – | – | |
| 64430 | H30 | 6351 | H30 | B51S | Al-Mg-Si 1 | AV | Al-Si-1 Mg Mn | 6082 |
| 6351 T6 Aluminium Plate Sizes: |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
| 6351 T6 Aluminium Plate Weight Chart: |
Width: 1.000 mm | Length: 2.000 mm
| Product | Thickness | Weight |
|---|---|---|
| 6351 T6 Aluminium Plate | 0,30 mm | 0,810 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,40 mm | 1,080 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,50 mm | 1,350 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,60 mm | 1,620 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,70 mm | 1,890 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,80 mm | 2,160 Kg/m2 |
| 6351 T6 Aluminium Plate | 0,90 mm | 2,430 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,00 mm | 2,700 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,20 mm | 3,240 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,40 mm | 3,780 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,50 mm | 4,050 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,60 mm | 4,320 Kg/m2 |
| 6351 T6 Aluminium Plate | 1,80 mm | 4,860 Kg/m2 |
| 6351 T6 Aluminium Plate | 2,00 mm | 5,400 Kg/m2 |
| 6351 T6 Aluminium Plate | 2,20 mm | 5,940 Kg/m2 |
| 6351 T6 Aluminium Plate | 2,50 mm | 6,750 Kg/m2 |
| 6351 T6 Aluminium Plate | 3,00 mm | 8,100 Kg/m2 |
| 6351 T6 Aluminium Plate | 4,00 mm | 10,800 Kg/m2 |
| 6351 T6 Aluminium Plate | 5,00 mm | 13,500 Kg/m2 |
| 6351 T6 Aluminium Plate | 6,00 mm | 16,200 Kg/m2 |
| 6351 T6 Aluminium Plate | 10,00 mm | 27,000 Kg/m2 |
| 6351 T6 Aluminium Plate | 12,00 mm | 32,400 Kg/m2 |
| 6351 T6 Aluminium Plate | 15,00 mm | 40,500 Kg/m2 |
| 6351 T6 Aluminium Plate | 20,00 mm | 54,000 Kg/m2 |
| 6351 T6 Aluminium Plate Chemical Composition: |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| H 30 | 64430 | 6351 | — | 0.1 | 0.4 | 1.2 | 0.6 | 1.3 | 0.6 | 0.4 | 0.3 | 0.3 | Zinc (4.5%) | ||
| Aluminium 6351 T6 Plate Mechanical Properties: |
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-6351 | O | – | 160 | – | 110 | 12 |
| T4 | 205 | – | 110 | – | 12 | |
| T6 | 290 | – | 250 | – | 6 | |
Aluminum Alloy Heat Treatment Temper Designations
Basic Aluminum Heat Treatment Designations
- F As Fabricated
- O Annealed
- H Strain Hardened
- W Solution Heat Treated
- T Solution Heat Treated
Heat Treating T Temper Codes for Aluminium 6351 T6 Plates
- T1 – Cooled from an elevated temperature shaping process and naturally aged to a substantially stable condition.
- T2 – Cooled from an elevated temperature shaping process, cold worked, and naturally aged to a substantially stable condition.
- T3 – Solution heat treated, cold worked, and naturally aged to a substantially stable condition.
- T4 – Solution heat treated, and naturally aged to a substantially stable condition.
- T5 – Cooled from an elevated temperature shaping process then artificially aged.
- T6 – Solution heat treated then artificially aged.
- T7 – Solution heat treated then overaged/stabilized.
- T8 – Solution heat treated, cold worked, then artificially aged.
- T9 – Solution heat treated, artificially aged, then cold worked.
- T10 – Cooled from an elevated temperature shaping process, cold worked, then artificially aged.
Additional digits may be used after the first T temper digit to indicate subsequent stress relieving by processes such as stretching, compressing, or a combination.
H Temper Strain Hardening Codes for Aluminium 6351 T6 Plates
- H1 – Strain hardened only
- H2 – Strain hardened and partially annealed
- H3 – Strain hardened and stabilized
- H4 – Strain hardened and lacquered or painted. This assumes that thermal affects from the coating process affect the strain hardening; seldom encountered.
Application of 6351 T6 Aluminium Plate
6351 T6 Aluminium Plate is the most widely used form of Industrial Aluminium. 6351 T6 Aluminium Plates find applications in various industries such as manufacturing cans and packages, transportation, home appliances, building and construction.
