64430 Aluminium Round Bar
Aluminum 64430 Round Bar is a grade of aluminum alloys. Their average alloy composition is basically identical. Aluminium 64430 Bar is a heat treatable alloy very similar to 6351 with similar characteristics including corrosion resistance and strength. Many European specifications now call up 6082 Aluminum Bar in lieu of Aluminum Flat Bar 6351.
64430 Aluminium Round Bar ASTM B221, EN573, and EN485 international standards.
Sasa Aluminium Incorporation is the leading manufacturer and exporter of 64430 Aluminium Round Bar. Supplier of ASTM B221 64430 Aluminium Round Bar in Tempers manufactured in accordance with international standards ASTM B221, ASME SB 221, EN573, and EN485, check 64430 Aluminium Round Bar price. Wholesale Trader of 64430 Commercial Aluminium Bar offered by Sasa Aluminium , China. Stockist of 64430 Aluminium Rod, H32 64430 Aluminium Hex Bar, H38 Commercial 64430 Aluminium Flat Bar, ASME SB221 64430 Aluminium Square Bar, 64430 Mill Finish, 64430 Aluminium Half Round Bar, 64430 Cold Finished Round Bar and 64430 Aluminium Cold Drawn Round Bar in China.
| Specifications of 64430 Aluminium Round Bar: |
| Aluminium Alloy | ASTM B221 64430 |
| Standard | ASTM, ASME, AMS, ASTM B221M, GB/T 3191, JIS H4040, ASTM B221, AMS QQ-A-200/9 |
| Aluminium 64430 Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium 64430 Bar Form | 64430 Aluminium Square, Round, Hex, Flat, Half Round, Oval, Angle, Rectangular, Wire in Black & Bright Finish |
| Aluminium 64430 Round Bar | Diameter:0.1-600mm,etc |
| Aluminium 64430 Hexagonal Bar | Diameter:0.1-600mm,etc |
| Aluminium 64430 Angle Bar | Size:0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium 64430 Flat Bar | Thickness:0.1-600mm,etc Width:1-2500mm,etc |
| Aluminium 64430 Square Bar | Size:1mm*1mm-800mm*800mm, etc |
| Aluminium 64430 Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium 64430 Bar | Bright, Polish & Black |
| Aluminium 64430 Bars Surface | Anodized, Polished, hair line, brush, Mill finished, Bright finish, paper interleaved |
| Aluminium 64430 Solid Round Bar Delivery Time | 10-30 days after receiving the prepayment |
| Aluminium 64430 Round Bar Packaging Details | Export standard package: bundled wooden box, suit for all kinds of transport or be required. |
| ASTM B221 Alloy 64430 Round Bar Outer packing | Export standard, wooden pallet |
| We Export Aluminium 64430 Round Bar to | Singapore, Indonesia, Ukraine, Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, USA, Egypt, Iran, China, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq, Russia, Malaysia, etc. |
| Types of 64430 Aluminium Round Bar Manufacturer in China: |
64430 Aluminium Threaded Rods stockholder in China, 64430 Aluminium Forged Round Bars wholesaler in China, Aluminium EN AW 64430 Cold Finish Round Bar importers in China, 64430 Aluminium Hexagonal Rods Cut To Size At Best Price
Standard Dimensions of 64430 Aluminium Round Bar
Standard dimensions
|
|
Aluminium 64430 Round Bar Manufacturers, Cold Drawn 64430 Aluminium Bar, Cold Forming 64430 Aluminium Material Rod, Cold Rolled 64430 Aluminium Round Rod, 64430 Aluminum Alloy Hollow Bar, UNS A96082 Round Bar Manufacturer in China, EN 485-2 64430 Aluminium Bars & Rods stockist, 64430 Aluminium Round Bar Price in China
| Standard Specification of 64430 Aluminium Round Bar: |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-6351 | HE30 | 6351 | AlMgSi1 | AlSiMg0.5Mn | 64430 | B51S |
| EN AW-6082 | HE30 | 6351 | AlMgSi1 | AlSi1MgMn | 64430 | B51S |
| 64430 Aluminium Round Bar Equivalent Grades: |
| China |
U.S.A. |
BRITAIN |
CANADA | GERMANY |
RUSSIA |
I.S.O. |
FRENCH | |
|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) |
(B.S.) |
(DIN) | – | – | – | |
| 64430 | H30 | 6351 | H30 | B51S | Al-Mg-Si 1 | AV | Al-Si-1 Mg Mn | 6082 |
| 64430 Aluminium Round Bar Weight Chart: |
| Product | Diameter | Weight |
|---|---|---|
| 64430 Aluminium Round Bar | 6 mm | 0,076 Kg/m |
| 64430 Aluminium Round Bar | 7 mm | 0,104 Kg/m |
| 64430 Aluminium Round Bar | 8 mm | 0,136 Kg/m |
| 64430 Aluminium Round Bar | 9 mm | 0,172 Kg/m |
| 64430 Aluminium Round Bar | 9,5 mm | 0,191 Kg/m |
| 64430 Aluminium Round Bar | 10 mm | 0,212 Kg/m |
| 64430 Aluminium Round Bar | 11 mm | 0,257 Kg/m |
| 64430 Aluminium Round Bar | 12 mm | 0,305 Kg/m |
| 64430 Aluminium Round Bar | 12,5 mm | 0,331 Kg/m |
| 64430 Aluminium Round Bar | 13 mm | 0,358 Kg/m |
| 64430 Aluminium Round Bar | 14 mm | 0,416 Kg/m |
| 64430 Aluminium Round Bar | 16 mm | 0,543 Kg/m |
| 64430 Aluminium Round Bar | 16,5 mm | 0,577 Kg/m |
| 64430 Aluminium Round Bar | 18 mm | 0,687 Kg/m |
| 64430 Aluminium Round Bar | 19 mm | 0,766 Kg/m |
| 64430 Aluminium Round Bar | 20 mm | 0,848 Kg/m |
| 64430 Aluminium Round Bar | 22 mm | 1,026 Kg/m |
| 64430 Aluminium Round Bar | 25 mm | 1,325 Kg/m |
| 64430 Aluminium Round Bar | 28 mm | 1,663 Kg/m |
| 64430 Aluminium Round Bar | 30 mm | 1,909 Kg/m |
| 64430 Aluminium Round Bar | 31 mm | 2,038 Kg/m |
| 64430 Aluminium Round Bar | 32 mm | 2,171 Kg/m |
| 64430 Aluminium Round Bar | 35 mm | 2,598 Kg/m |
| 64430 Aluminium Round Bar | 38 mm | 3,062 Kg/m |
| 64430 Aluminium Round Bar | 40 mm | 3,393 Kg/m |
| 64430 Aluminium Round Bar | 45 mm | 4,294 Kg/m |
| 64430 Aluminium Round Bar | 50 mm | 5,301 Kg/m |
| 64430 Aluminium Round Bar | 55 mm | 6,415 Kg/m |
| 64430 Aluminium Round Bar | 60 mm | 7,634 Kg/m |
| 64430 Aluminium Round Bar | 65 mm | 8,959 Kg/m |
| 64430 Aluminium Round Bar | 70 mm | 10,391 Kg/m |
| 64430 Aluminium Round Bar | 75 mm | 11,928 Kg/m |
| 64430 Aluminium Round Bar | 80 mm | 13,572 Kg/m |
| 64430 Aluminium Round Bar | 90 mm | 17,177 Kg/m |
| 64430 Aluminium Round Bar | 100 mm | 21,206 Kg/m |
| 64430 Aluminium Round Bar | 105 mm | 23,379 Kg/m |
| 64430 Aluminium Round Bar | 110 mm | 25,659 Kg/m |
| 64430 Aluminium Round Bar | 120 mm | 30,536 Kg/m |
| 64430 Aluminium Round Bar | 127 mm | 34,203 Kg/m |
| 64430 Aluminium Round Bar | 130 mm | 35,838 Kg/m |
| 64430 Aluminium Round Bar | 140 mm | 41,563 Kg/m |
| 64430 Aluminium Round Bar | 150 mm | 47,713 Kg/m |
| 64430 Aluminium Round Bar | 180 mm | 68,707 Kg/m |
| 64430 Aluminium Round Bar | 200 mm | 84,823 Kg/m |
Theorical Weights Table
The values presented on this table are theorical and they should be confirmed if you make an order.
| 64430 Aluminium Square Bar Weight Chart: |
| Product | Side | Weight |
|---|---|---|
| Aluminium Square Bar | 10 mm | 0,270 Kg/m |
| Aluminium Square Bar | 15 mm | 0,608 Kg/m |
| Aluminium Square Bar | 16 mm | 0,691 Kg/m |
| Aluminium Square Bar | 20 mm | 1,080 Kg/m |
| Aluminium Square Bar | 25 mm | 1,688 Kg/m |
| Aluminium Square Bar | 35 mm | 3,308 Kg/m |
| Aluminium Square Bar | 45 mm | 5,468 Kg/m |
| Aluminium Square Bar | 60 mm | 9,720 Kg/m |
| Aluminium Square Bar | 100 mm | 27,000 Kg/m |
| 64430 Aluminium Rectangular Bar Weight Chart: |
| Product | Width | Thickness | Weight | |
|---|---|---|---|---|
| 64430 Aluminium Rectangular Bar | 20 mm | x | 2 mm | 0,108 Kg/m |
| 64430 Aluminium Rectangular Bar | 15 mm | x | 3 mm | 0,122 Kg/m |
| 64430 Aluminium Rectangular Bar | 20 mm | x | 3 mm | 0,162 Kg/m |
| 64430 Aluminium Rectangular Bar | 25 mm | x | 3 mm | 0,203 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 3 mm | 0,243 Kg/m |
| 64430 Aluminium Rectangular Bar | 40 mm | x | 3 mm | 0,324 Kg/m |
| 64430 Aluminium Rectangular Bar | 15 mm | x | 4 mm | 0,162 Kg/m |
| 64430 Aluminium Rectangular Bar | 20 mm | x | 4 mm | 0,216 Kg/m |
| 64430 Aluminium Rectangular Bar | 25 mm | x | 4 mm | 0,270 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 4 mm | 0,324 Kg/m |
| 64430 Aluminium Rectangular Bar | 15 mm | x | 5 mm | 0,203 Kg/m |
| 64430 Aluminium Rectangular Bar | 20 mm | x | 5 mm | 0,270 Kg/m |
| 64430 Aluminium Rectangular Bar | 25 mm | x | 5 mm | 0,338 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 5 mm | 0,405 Kg/m |
| 64430 Aluminium Rectangular Bar | 40 mm | x | 5 mm | 0,540 Kg/m |
| 64430 Aluminium Rectangular Bar | 50 mm | x | 5 mm | 0,675 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 6 mm | 0,486 Kg/m |
| 64430 Aluminium Rectangular Bar | 40 mm | x | 6 mm | 0,648 Kg/m |
| 64430 Aluminium Rectangular Bar | 60 mm | x | 6 mm | 0,972 Kg/m |
| 64430 Aluminium Rectangular Bar | 20 mm | x | 8 mm | 0,432 Kg/m |
| 64430 Aluminium Rectangular Bar | 25 mm | x | 8 mm | 0,540 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 8 mm | 0,648 Kg/m |
| 64430 Aluminium Rectangular Bar | 40 mm | x | 8 mm | 0,864 Kg/m |
| 64430 Aluminium Rectangular Bar | 50 mm | x | 8 mm | 1,080 Kg/m |
| 64430 Aluminium Rectangular Bar | 55 mm | x | 8 mm | 1,188 Kg/m |
| 64430 Aluminium Rectangular Bar | 60 mm | x | 8 mm | 1,296 Kg/m |
| 64430 Aluminium Rectangular Bar | 80 mm | x | 8 mm | 1,728 Kg/m |
| 64430 Aluminium Rectangular Bar | 100 mm | x | 8 mm | 2,160 Kg/m |
| 64430 Aluminium Rectangular Bar | 20 mm | x | 10 mm | 0,540 Kg/m |
| 64430 Aluminium Rectangular Bar | 25 mm | x | 10 mm | 0,675 Kg/m |
| 64430 Aluminium Rectangular Bar | 30 mm | x | 10 mm | 0,810 Kg/m |
| 64430 Aluminium Rectangular Bar | 40 mm | x | 10 mm | 1,080 Kg/m |
| 64430 Aluminium Rectangular Bar | 50 mm | x | 10 mm | 1,350 Kg/m |
| 64430 Aluminium Rectangular Bar | 60 mm | x | 10 mm | 1,620 Kg/m |
| 64430 Aluminium Rectangular Bar | 80 mm | x | 10 mm | 2,160 Kg/m |
| 64430 Aluminium Rectangular Bar | 100 mm | x | 10 mm | 2,700 Kg/m |
| 64430 Aluminium Rectangular Bar | 200 mm | x | 20 mm | 10,800 Kg/m |
| 64430 Aluminium Round Bar Chemical Composition: |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| H 30 | 64430 | 6351 | — | 0.1 | 0.4 | 1.2 | 0.6 | 1.3 | 0.6 | 0.4 | 0.3 | 0.3 | Zinc (4.5%) | ||
| Aluminium 64430 Round Bar Mechanical Properties: |
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-6351 | O | – | 160 | – | 110 | 12 |
| T4 | 205 | – | 110 | – | 12 | |
| T6 | 290 | – | 250 | – | 6 | |
Aluminum Alloy Heat Treatment Temper Designations for Round Bars
Basic Aluminum Heat Treatment Designations
- F As Fabricated
- O Annealed
- H Strain Hardened
- W Solution Heat Treated
- T Solution Heat Treated
Heat Treating T Temper Codes for Aluminium 64430 Round Rods
- T1 – Cooled from an elevated temperature shaping process and naturally aged to a substantially stable condition.
- T2 – Cooled from an elevated temperature shaping process, cold worked, and naturally aged to a substantially stable condition.
- T3 – Solution heat treated, cold worked, and naturally aged to a substantially stable condition.
- T4 – Solution heat treated, and naturally aged to a substantially stable condition.
- T5 – Cooled from an elevated temperature shaping process then artificially aged.
- T6 – Solution heat treated then artificially aged.
- T7 – Solution heat treated then overaged/stabilized.
- T8 – Solution heat treated, cold worked, then artificially aged.
- T9 – Solution heat treated, artificially aged, then cold worked.
- T10 – Cooled from an elevated temperature shaping process, cold worked, then artificially aged.
Additional digits may be used after the first T temper digit to indicate subsequent stress relieving by processes such as stretching, compressing, or a combination.
H Temper Strain Hardening Codes for Aluminium 64430 Bars
- H1 – Strain hardened only
- H2 – Strain hardened and partially annealed
- H3 – Strain hardened and stabilized
- H4 – Strain hardened and lacquered or painted. This assumes that thermal affects from the coating process affect the strain hardening; seldom encountered.
Application of 64430 Aluminium Rod/ Round Bar
64430 Aluminium Round Bar is the most widely used form of Industrial Aluminium. 64430 Aluminium Rods find applications in various industries such as manufacturing cans and packages, transportation, home appliances, building and construction.
