74530 Aluminium Plate
The only high strength, wrought, 7000 series aluminum alloy with a military specification is the 74530 aluminum-zinc alloy Plate, controlled by MIL-DTL-46063H(MR). Aluminium / aluminum 74530 Plate is a heat treatable wrought alloy. The 7075 Aluminium Plate is similar to 74530 aluminum armor plate, but with higher strength.
Sasa Aluminium is the leading manufacturer and exporter of 74530 Aluminium Plate. Supplier of ASTM B209 74530 Aluminium Plate from 0.5mm to 5mm Thick 1000mm x 1000mm to 2500mm x 1250mm Tempers manufactured in accordance with international standards ASTM B209, ASTM-B-209, EN573, and EN485, check 74530 Aluminium Plate price. The general widths of 74530 H16 Aluminum Plates are 1000mm, 1250mm and 1500mm, while common lengths are 2000mm, 2500 mm and 3000mm respectively. Wholesale Trader of 74530 Commercial Aluminium Plate offered by Sasa Aluminium , China. Stockist of 74530 Aluminium Plate, H32 74530 Aluminium Stucco Plate, H38 Commercial 74530 Aluminium Plate, ASME SB209 74530 Aluminium Patterned Plate, 74530 Mill Finish, 74530 Aluminium Extruded Plate, 74530 Aluminium Plate and 74530 Aluminium Plate in China.
| Standard Dimensions of 74530 Aluminium Plate: |
| Aluminium Alloy | ASTM B209 74530 |
| Aluminium 74530 Plate Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium 74530 Plate Thickness | 0.5mm-150mm |
| Aluminium 74530 Plate Width | 500-2000mm |
| Aluminium 74530 Plate Length | to clients’ requirement |
| Aluminium 74530 Plate Coating | Polyester, Fluorocarbon, polyurethane and epoxy coating |
| 74530 Aluminium Plate Coating finish | PVDF, POLYESTER(PE) |
| Aluminium 74530 Plate Surface | Polished, hair line, brush, sand blast, checkered, embossed, etching, etc. Mill finish, Bright finish, paper interleaved, one side film, both sides film. |
| Aluminium 74530 Plate Gloss | Meet the customer requirement |
| Total coating thickness of Aluminium 74530 Plate | PVDF coating: More than 25 micron; Polyester coating: More than 18 micron |
| Aluminium 74530 Plate Coating hardness | (pencil hardness) more than 2H |
| Aluminium 74530 Plate Coating adhesive | No lower than1st grade |
| Aluminium 74530 Plate Impact resistance | No cracking or peeling (50kg/cm, ASTMD-2794: 1993) |
| Aluminium 74530 Plate Flexibility (T-bend) | 2T |
| Aluminium 74530 Plate MEK resistance | More than 10 |
| Available Aluminium 74530 Plate Stock Sizes | 1ft x 1ft, 1ft x 2ft, 1ft x 4ft, 2ft x 2ft, 2ft x 4ft, 4ft x 4ft, 4ft x 8ft, 4ft x 10ft or Cut to Size or Custom Shape. |
| Aluminium 74530 Plate Delivery Time | 30-60 days after receiving the prepayment |
| Aluminium 74530 Plate Packaging Details | Standard export package. One pallet is about 2-3 ton.Two steel belts in width and three in width. One 20GP container can load about 18-20 tons Aluminium 74530 Plate. One 40GP container can load about 24 tons Aluminium 74530 Plate |
| ASTM B209 Alloy 74530 Plate Outer packing | Export standard, wooden pallet |
| Bottom side Aluminium 74530 Plate is coated with protective polyester material, thickness more than 6 micron | |
| We Export Aluminium 74530 Plate to | Singapore, Indonesia, Ukraine, Korea, Thailand, Vietnam, Saudi Arabia, Brazil, Spain, Canada, USA, Egypt, Iran, China, Kuwait, Dubai, Oman, Kuwait, Peru, Mexico, Iraq, Russia, Malaysia, etc. |
| Types of 74530 Aluminium Plate Manufacturer in China |
| 74530 Aluminium Plates Product Range | ||||
|---|---|---|---|---|
| Alloy No. | Thickness (mm) |
Width (mm) |
Length (mm) |
Temper |
| 74530 Aluminium Plate | 0.2-5.0 | 20-2200 | 20-8000 | O, H12, H22, H14, H16, H18, H24, H26 |
| Standard Specification of 74530 Aluminium Plate: |
| China |
U.S.A. |
BRITAIN |
CANADA | GERMANY |
RUSSIA |
I.S.O. |
FRENCH | |
|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) |
(B.S.) |
(DIN) | – | – | – | |
| 74530 | – | 7039 | – | D74S | – | – | 3004 | |
| 74530 Aluminium Plate Equivalent Grades: |
| China |
U.S.A. |
BRITAIN |
CANADA | GERMANY |
RUSSIA |
I.S.O. |
FRENCH | |
|---|---|---|---|---|---|---|---|---|
| New IS | Old IS | (A.A.) |
(B.S.) |
(DIN) | – | – | – | |
| 74530 | – | 7039 | – | D74S | – | – | 3004 | |
| 74530 Aluminium Plate Sizes: |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
| 74530 Aluminium Plate Weight Chart: |
Width: 1.000 mm | Length: 2.000 mm
| Product | Thickness | Weight |
|---|---|---|
| 74530 Aluminium Plate | 0,30 mm | 0,810 Kg/m2 |
| 74530 Aluminium Plate | 0,40 mm | 1,080 Kg/m2 |
| 74530 Aluminium Plate | 0,50 mm | 1,350 Kg/m2 |
| 74530 Aluminium Plate | 0,60 mm | 1,620 Kg/m2 |
| 74530 Aluminium Plate | 0,70 mm | 1,890 Kg/m2 |
| 74530 Aluminium Plate | 0,80 mm | 2,160 Kg/m2 |
| 74530 Aluminium Plate | 0,90 mm | 2,430 Kg/m2 |
| 74530 Aluminium Plate | 1,00 mm | 2,700 Kg/m2 |
| 74530 Aluminium Plate | 1,20 mm | 3,240 Kg/m2 |
| 74530 Aluminium Plate | 1,40 mm | 3,780 Kg/m2 |
| 74530 Aluminium Plate | 1,50 mm | 4,050 Kg/m2 |
| 74530 Aluminium Plate | 1,60 mm | 4,320 Kg/m2 |
| 74530 Aluminium Plate | 1,80 mm | 4,860 Kg/m2 |
| 74530 Aluminium Plate | 2,00 mm | 5,400 Kg/m2 |
| 74530 Aluminium Plate | 2,20 mm | 5,940 Kg/m2 |
| 74530 Aluminium Plate | 2,50 mm | 6,750 Kg/m2 |
| 74530 Aluminium Plate | 3,00 mm | 8,100 Kg/m2 |
| 74530 Aluminium Plate | 4,00 mm | 10,800 Kg/m2 |
| 74530 Aluminium Plate | 5,00 mm | 13,500 Kg/m2 |
| 74530 Aluminium Plate | 6,00 mm | 16,200 Kg/m2 |
| 74530 Aluminium Plate | 10,00 mm | 27,000 Kg/m2 |
| 74530 Aluminium Plate | 12,00 mm | 32,400 Kg/m2 |
| 74530 Aluminium Plate | 15,00 mm | 40,500 Kg/m2 |
| 74530 Aluminium Plate | 20,00 mm | 54,000 Kg/m2 |
| 74530 Aluminium Plate Chemical Composition: |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| — | 74530 | 7039 | — | 0.2 | 1.0 | 1.5 | — | 0.4 | 0.7 | 0.2 | 0.7 | 0.4 | Zinc (5.1-6.1) & Chromium (0.2-0.28) | ||
| Aluminium 74530 Plate Mechanical Properties: |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength (@diameter 12.7 mm/0.500 in) | 450 MPa | 65300 psi |
| Yield strength (@diameter 12.7 mm/0.500 in) | 380 MPa | 55100 psi |
| Elongation at break (@diameter 12.7 mm/0.500 in) | 13% | 13% |
| Elastic modulus | 69.6 GPa | 10100 ksi |
| Shear strength | 255 MPa | 37000 psi |
| Hardness, Brinell (@load 500 kg; thickness 10.0 mm/1100 lb;0.394 in) | 133 | 133 |
| Hardness, Knoop (converted from Brinell hardness value) | 167 | 167 |
| Hardness, Rockwell A (converted from Brinell hardness value) | 50 | 50 |
| Hardness, Rockwell B (converted from brinell hardness value) | 81 | 81 |
| Hardness, Vickers (converted from Brinell hardness value) | 153 | 153 |
Aluminum Alloy Heat Treatment Temper Designations
Basic Aluminum Heat Treatment Designations
- F As Fabricated
- O Annealed
- H Strain Hardened
- W Solution Heat Treated
- T Solution Heat Treated
Heat Treating T Temper Codes for Aluminium 74530 Plates
- T1 – Cooled from an elevated temperature shaping process and naturally aged to a substantially stable condition.
- T2 – Cooled from an elevated temperature shaping process, cold worked, and naturally aged to a substantially stable condition.
- T3 – Solution heat treated, cold worked, and naturally aged to a substantially stable condition.
- T4 – Solution heat treated, and naturally aged to a substantially stable condition.
- T5 – Cooled from an elevated temperature shaping process then artificially aged.
- T6 – Solution heat treated then artificially aged.
- T7 – Solution heat treated then overaged/stabilized.
- T8 – Solution heat treated, cold worked, then artificially aged.
- T9 – Solution heat treated, artificially aged, then cold worked.
- T10 – Cooled from an elevated temperature shaping process, cold worked, then artificially aged.
Additional digits may be used after the first T temper digit to indicate subsequent stress relieving by processes such as stretching, compressing, or a combination.
H Temper Strain Hardening Codes for Aluminium 74530 Plates
- H1 – Strain hardened only
- H2 – Strain hardened and partially annealed
- H3 – Strain hardened and stabilized
- H4 – Strain hardened and lacquered or painted. This assumes that thermal affects from the coating process affect the strain hardening; seldom encountered.
Application of 74530 Aluminium Plate
74530 Aluminium Plate is the most widely used form of Industrial Aluminium. 74530 Aluminium Plates find applications in various industries such as manufacturing cans and packages, transportation, home appliances, building and construction.
